COMBINED EQUIPMENT SOLUTIONS
Eurolls is able to design and supply different kind of concepts of multiple or single in-line wire rolling processes.
Examples of applications:
- In-line for lattice girder production;
- In-line for simple or twisted bar production;
- In-line for mesh longitudinal-transverse wire production.
| NQRC Series | 760/610-30 | 760/610-45 | 900/610-55 | 900/610-123 | 900/610-172 TWIN | |
|---|---|---|---|---|---|---|
| MAX. INPUT WIRE FOR COLD ROLLING | [mm] | 5.5 ÷ 11 | 5.5 ÷ 11 | 5.5 ÷ 12 | 5.5 ÷ 14 | 5.5 ÷ 14 |
| MAX. INPUT WIRE FOR STRECHING | [mm] | 6.0 ÷ 10 | 6.0 ÷ 10 | 6.0 ÷ 12 | 6.0 ÷ 12 | 6.0 ÷ 12 |
| MIN. OUTPUT WIRE COLD ROLLED | [mm] | 4.0 ÷ 10 | 4.0 ÷ 10 | 3.4 ÷ 10 | 3.4 ÷ 12 | 3.4 ÷ 12 |
| MIN. OUTPUT WIRE STRECHED | [mm] | 6.0 ÷ 10 | 6.0 ÷ 10 | 6.0 ÷ 12 | 6.0 ÷ 12 | 6.0 ÷ 12 |
| MAX. SPEED | [m/s] | 2 | 3 | 3 | 8 | 6 |
| NUMBER OF DRAFTS | 2 | 2 | 2 | 2 | 2 | |
| NUMBER OF CASSETTES | 2+1 | 2+1 | 2+2 | 2+2 | 2+2 |
