CONCRETE FIBER MACHINES

CONCRETE FIBER MACHINES

The machine guarantees a high and continuous production of steel fiber and, with the appropriate tools, can be preset for the production of any type, shape and dimension.
The particularity of this machine is the introduction of a new concept that combines the simplicity of operation with high performance and productivity. A further innovation element is the wide tolerance range of the inlet wire material, so broad that it allows to transform scrap wire, considered out of tolerance from other processes, into a final product with high market value.

IF Series   IF60
WIRE DIAMETER RANGE [mm] 0.8 - 1.2
WIRE TOLERANCES [mm] ± 0.05
MAX NUMBER OF WIRES [-] 40
INSTALLED POWER [Kw] 24
MAX WORKING SPEED [m/s] 1,5
PRODUCTION [t/h] 0.85 - 1.9
WORKING COIL WEIGHT   as per client’s specification
WORKING COIL DIMENSIONS   as per client’s specification
