NAIL MACHINERY

NAIL MACHINERY

This new wide range of nail machines enables a higher nail per minute output and the production of clean and burr free nail as well, for most nail manufacturing requirements. This is the result of a very long experience in the fastener field and an awareness to today’s nail-makers’ needs.

The Vitari nail making machines are manufactured to the highest standards in order to guarantee continuous high-speed nail output; the machine components are therefore engineered and manufactured to sustain long and uninterrupted working sessions. The three main shafts of the machine are all made of high-grade forged steel, induction hardened and equipped with an automatic centralized lubrication system, timer controlled, operating at regular intervals. The most popular models VR17-VR20-VR23 are supplied with an additional lubricating system that ensures continuous lubrication of the main shaft, connecting rod and hammer.

The VR series of nail making machines was designed to a very low noise rating thanks to the use of soundproof cabins (abt. 80db) designed specifically for each machine model.

Nail VR Series
MODEL   VR 10 VR 14 VR 17 VR 20 VR 20 S VR 23 VR 23 S VR 27 VR 30
WIRE Ø INPUT [mm] 0.6 ÷ 1.5 1.0 ÷ 2.4 1.8 ÷ 3.4 2.2 ÷ 4.4 2.2 ÷ 4.4 3.0 ÷ 5.2 3.0 ÷ 6.0 5.4 ÷ 8.0 7.0 ÷ 10.0
NAIL LENGTH [mm] 6 ÷ 30 15 ÷ 50 20 ÷ 75 30 ÷ 105 30 ÷ 120 30 ÷ 150 30 ÷ 180 50 ÷ 250 50 ÷ 300
MAX. SPEED [pcs/min] 950 720 550 420 400 370 300 180 150
